Easiloc – EL350

  • Tamper-evident

  • 4 Lengths 200-350mm

  • 23-25kg Breaking Strain

Manufactured by Talisman in Great Malvern. The Talisman Easiloc EL range of pull tight seals are manufactured from polypropylene, and are available with strap lengths of 200, 250, 300 and 350mm.

A tear off feature is included in the seal tag, which allows it to be removed without the need for cutting tools. This enhances health and safety requirements by removing the need for cutting tools and eliminates the cost of these tools.

A rib is moulded on the reverse side of the strap to ensure correct entry when applying the seal.

A return loop catch is included just above the seal locking head, which allows excess strap to be tucked away, improving health and safety requirements and can also be used as a label carrier.

Category:

Dimensions

Easiloc Dimensions

PRODUCT CODE DIMENSIONS – mm
STRAP LENGTH SL OPERATING LENGTH OL STRAP WIDTH SW TAG LENGTH TL TAG WIDTH TW
Easiloc EL200 200 152 5 47 19.5
Easiloc EL250 250 200 5 47 19.5
Easiloc EL300 300 248 5 47 19.5
Easiloc EL350 350 296 5 47 19.5

Technical Data

Applications

Security sealing bags, sacks, tote box lids, roll cages and more.

Material

Polypropylene

Average Breaking Strain

  • EL200 – 23kgf
  • EL250 – 24kgf
  • EL300 – 24kgf
  • EL350 – 25kgf

Packaging

Mats of 10 in cartons of 500

Marking

  • Laser printing
  • Standard product has a sequential serial number
  • 2 lines of additional text available
  • Optional logos and barcoding

Colours

Standard colours – red, green, blue and yellow
Non-standard colours may be available on request

Shipping Specification

Carton dimensions: 412 x 250 x 205mm
